Cross tube out of cut-off
Korsrör utan avstick DIN - Image 2
Stainless steel T-pipes
Article Number: Cross tube without offsets DIN

Cross tube without offsets DIN

Our hygienic cross tubes without branches are used in the pharmaceutical, food, cosmetic and chemical-technical industries. They are manufactured according to the DIN dimensional standard.

Available with internal surface roughness of Ra 0.8. All sizes in the table below are in mm.

See variations (10)
Dimensional standard
DIN
DIN (Deutsches Institut für Normung) A European standard, commonly used in Germany and other parts of Europe. DIN dimensions are characterized by metric pipe size and good fit with other DIN components, often used in industry, process and food.
Article Number Dimension mm T R A Execution Availability Price
46-31-DIN100S 104 2 155 155 Ra 0,8 µm Login to see availability and prices
46-31-DIN10S 13 1.5 35 35 Ra 0,8 µm Login to see availability and prices
46-31-DIN15S 19 1.5 35 35 Ra 0,8 µm Login to see availability and prices
46-31-DIN20S 23 1.5 40 40 Ra 0,8 µm Login to see availability and prices
46-31-DIN25S 29 1.5 50 50 Ra 0,8 µm Login to see availability and prices
46-31-DIN32S 35 1.5 55 55 Ra 0,8 µm Login to see availability and prices
46-31-DIN40S 41 1.5 60 60 Ra 0,8 µm Login to see availability and prices
46-31-DIN50S 53 1.5 80 80 Ra 0,8 µm Login to see availability and prices
46-31-DIN65S 70 2 105 105 Ra 0,8 µm Login to see availability and prices
46-31-DIN80S 85 2 130 130 Ra 0,8 µm Login to see availability and prices
